Timeguard 24 Hour/7 Day 10 Amp Electro-Mechanical Time Controller

Stock Code: SYN269H

Surface mount with changeover dial to allow either 24 hour or 7 day operation with colour coded switching tappets.

10(2)A (2.3kW) loading.
Changeover dial allows 24 hour or 7 day operation.
Optional panel mount (clip included).
Manual override until next programme change & permanent ON/OFF.
20 minute minimum switching interval which can be increased in 5 minute steps (24 hour operation).
2 hour minimum switching interval which can be increased in 30 minute steps (7 day operation).
72 × 72mm plug-in base surface mount.
Synchronous motor driven.
Time display for ease of operation.
Tamper proof transparent cover.
Mounting Options: 68mm square panel hole with the aid of mounting bracket AK305 supplied with product. They can also be mounted on DIN rail using adaptor 9070071.
